A0139901201 - COMBI SCREW

COMBI SCREW

Part № A0139901201

Coating DBL 9440.50
headtype Pan
threadsize M6
totallength 16
Request quantity

Technical details

Feature images are indicative only. Refer to technical drawing for final dimensions.

Box quantity

500
HasPilot

1
HasWasher

1
HeadDiam

11.8
HeadHeight

4.5
HeadType

Pan
Length

12.9
LockingType

Undefined
PilotType

Cone
PropertyClass

SteelPC8_8
ThreadLength

11.9
ThreadPitch

1
ThreadSize

M6
ThreadSpecial

Standard
ThreadType

Metric
ToolSize

30
ToolType

InternalTorx
TotalLength

16
WasherDiam

22
WasherHeight

1
WasherType

Flat
Coating View details

Features

Bolts technical drawing

Do you have any questions about this product?

Richard, our product expert on external threaded fasteners is ready to answer all your questions.

Technical support

A0139901201

Discover the versatility and functionality of the COMBI SCREW, part number A0139901201, designed to provide reliable connections in various applications. Available in boxes of 500, this bolt ensures you have an ample supply for any project. Crafted from SteelPC8.8, it delivers the strength and durability essential for demanding environments.

The screw features a pan head design with a diameter of 11.8 mm and a height of 4.5 mm, ensuring a secure fit. Its M6 thread size, paired with a thread pitch of 1 mm, provides a precise and dependable connection. With a total length of 16 mm and a thread length of 11.9 mm, it meets a range of installation needs with ease.

The COMBI SCREW is equipped with a flat washer integrated into the design, enhancing stability and load distribution. Its washer diameter of 22 mm and height of 1 mm complement the secure fitting ensured by the internal Torx tool type.

Designed with a cone pilot type, this bolt ensures smooth and accurate installation. Ideal for projects that demand both performance and precision, the COMBI SCREW is your go-to solution for robust fastening.

Whether you are in the automotive industry or tackling a DIY project, the COMBI SCREW offers reliability and ease of use. Its comprehensive dimensions and quality materials make it suitable for dynamic and static applications, providing peace of mind in every connection. It reflects meticulous engineering to withstand vibration and maintain its hold over time.
