Technical details
Feature images are indicative only. Refer to technical drawing for final dimensions.
| Comment | head diameter will change |
|---|---|
| DriveSide | A |
| LengthA | 21.4 |
| LengthB | 18.9 |
| LockingTypeA | Undefined |
| LockingTypeB | Undefined |
| PilotTypeA | Undefined |
| PilotTypeB | Undefined |
| PropertyClass | SteelPC8_8 |
| StudLength | 64.5 |
| ThreadLengthA | 21.4 |
| ThreadLengthB | 18.9 |
| ThreadPitchA | 1,25 |
| ThreadPitchB | 1,25 |
| ThreadSizeA | |
| ThreadSizeB | M8 |
| ThreadSpecialA | Standard |
| ThreadSpecialB | Standard |
| ThreadTypeA | Metric |
| ThreadTypeB | Metric |
| ToolType | Undefined |
| WasherType | Undefined |
| Coating | View details |
